ensemble® massimo fuoco™

Integroitu vahvistin

Integrated amplifier with tube input stage
(2 x ECC801S, NOS),

power stage with bipolar transistors 2 x 100/150 W 8/4 Ohm.

Isolation transformer. 6 LINE level inputs (of which 1 in Monitor mode). Balance control.

Dimensions W x H x D: 395 x 135 x 315 mm. Weight 15.8 kg

Solid aluminium remote control
Supplied with 1.5 m Luminoso™ power cord and remote control.

Tubesox™ (tube dampers) fitted.

Al-Zorbo™ equipment platform recommended (optional).

Integroitu vahvistin

MASSIMO FUOCO™ 15.300 €

Hinta sisältää alv 25.5 %

Fuoco3 — The FUOCO has all the qualities and attributes to be the pulsating heart of a very high quality music system. With all the necessary controls available both manually and by remote, it offers both ease and the quality of touch. A few bars of music and the FUOCO grabs the listener’s attention through its natural expressiveness and lively immediacy.

Katso tekniset tiedot/specifications

Power nominal	100 W / 8 ohm 150 W / 4 ohm per channel
Input sensitivity	0.36 V (150 W / 4 ohm)
Input impedance	45 kohm
Signal-to-noise-ratio	99 dB (full power 4 ohm to noise floor)
THD+N	0.2 % (1 W / 4 ohm / 1 kHz)
Negative feedback	20 dB
Input tubes	Selected, matched ECC 81 (12AT7)
Voltage selector	100 V, 115 V, and 230 V (50/60 Hz) mains
Mains fuses	2 x 3.15 A T / 250 V (slow-blow) 220-240 V mains 2 x 5 A T / 250 V (slow-blow) 100-120 V mains
Power supply fuses	4 x 4 A T / 250 V (slow-blow)
Speaker output fuses	2 x 6.3 A FF / 250 V (super-fast)
Speaker outputs	Ensemble SYNERGIA binding posts, accepting 6 mm bananas (100 ampere-rated) 4 mm bananas 8 mm spades 10mm²- AWG7 nude cable
Dimensions (wdh)	395 x 315 x 135 mm (15.5″ x 12.4″ x 5.3″) (wdh) 550 x 430 x 350 mm (21.6″ x 17″ x 13.8″) boxed
Weight	15.5 kg (34 lbs) net, 19 kg (42 lbs) shipping weight
Accessories	Remote control handset TUBESOX™ tube dampers FLEXO™ shielded power cord (1.5 m) optional ZORBO™ equipment platform
Warranty	2 years on parts (tubes 6 months) with the exception of all cases of failure due to mishandling, unauthorized modification,or overvoltage.

ensemble_Fonobrio_back — The FONOBRIO is radical and without compromise, taking things right to the technical limits and phono reproduction to a new level. It blows away the ground level mists that still blurred a last layer of information sitting in the ‘grooved landscape’.

ensemble® massimo fonobrio™

Levysoitinetuvahvistin

Phono preamplifier (MM/MC) in dual mono design, fully discrete circuitry.

Direct (DC) coupled, class A output stage. (AC coupling option inside).

Extremely low noise floor. Very high resolution.

Separate MC and MM inputs. MC: two gain stages. Total gain max 74 dB

Adjustable impedance for MC (rear), adjustable output (inside).

Dimensions W x H x D: 395 x 135 x 315 mm. Weight 9 kg.

Luminoso™ power cord 1.5 m included.

Al-Zorbo™ equipment platform recommended (optional).

Levysoitinetuvahvistin

MASSIMO FONOBRIO ™ 11.000 €

Hinta sisältää alv 25.5 %

Katso tekniset tiedot/specifications

Bandwidth	10 Hz – 85 kHz (-3 dB points)
RIAA Accuracy	20 Hz – 20 kHz ±1 dB
Line Level Output	Max. 9.5 VRMS Phase correct Tolerating low impedance loads of > 3 kohm Output impedance < 100 ohm
Maximum Input	MC 4 mV MM 60 mV (= 23.5 dB overload margin)
Sensitivity / Gain	MC 250 µV for 4 mV output : 24 dB gain setting MC 125 µV for 4 mV output : 30 dB gain setting MM 4 mV for 640 mV output : 44 dB gain Total maximum gain (MC : 30 dB) : 74 dB
Input impedance	MC switchable between 16 values (51.7 ohm – 1 kohm)
Input capacitance	MC in parallel with 2300 pF MC custom value insertable internally MM 47 kohms in parallel with 220 pF
Total	MC better than –68 dB, referenced to 0.775 VRMS, unweighted
Hum and Noise	MC better than –74 dB, A weighted
(20 Hz – 20 kHz)	MM better than –80 dB, referenced to 0.775 VRMS, unweighted
THD	< 0.03%, MC input, 24 dB gain setting, Referenced to 0.775 mVRMS
Mains voltage (switchable)	100 V 50-60 Hz 115 V 50-60 Hz 230 V 50-60 Hz
Mains fuses	2 x 0.1 A T / 250 V slow-blow for 100 – 230 VAC
Power Switch	115 V neon light (Ba9s bayonet socket)
Dimensions (wdh)	395 x 315 x 138 mm (15.5″x 12.4″x 5.4″) 550 x 430 x 350 mm (21.6″x 17″x 13.8″) boxed
Weight	8.5 kg (18.5 lbs) net, 12 kg (26 lbs) shipping weight
Warranty	2 years on parts with the exception of faults due to mishandling, unauthorized modification or overvoltage

ensemble® massimo evivo™

Päätevahvistin

Power amplifier with tube input stage (2 x ECC801S, NOS), power stage with bipolar transistors 2 x 100/150 W 8/4 Ohm. Isolation transformer.

RCA / cinch inputs.

Dimensions W x H x D: 395x135x315 mm. Weight 15.6 kg.

Supplied with Luminoso™ power cord 1.5 m.

Tubesox™ (tube dampers) fitted.

Al-Zorbo™ equipment platform recommended (optional)

Päätevahvistin

MASSIMO EVIVO ™ 12.900 €

Hinta sisältää alv 25.5 %

ensemble_Evivo2 — The EVIVO power amplifier is a true state-of-the-art product, built to the highest Swiss standards of precision and quality. It has an almost uncanny ability to make music come alive with spine-tingling immediacy and natural expressiveness.

Katso tekniset tiedot/specifications

Power nominal	100 W / 8 ohm 150 W / 4 ohm per channel
Input sensitivity	1.1 V (150 W / 4 ohm)
Input impedance	20 kohm
Signal-to-noise-ratio	99 dB (full power 4 ohm to noise floor)
THD + N	0.2 % (1 W / 4 ohm / 1 kHz)
Negative feedback	20 dB
Input tubes	Selected, matched ECC 81 (12AT7)
Voltage selector	100 V, 115 V, and 230 V (50/60 Hz) mains
Mains fuses	2 x 3.15 A T / 250 V (slow-blow) 220-240 V mains 2 x 5 A T / 250 V (slow-blow) 100-120 V mains
Power supply fuses	4 x 4 A T / 250 V (slow-blow)
Speaker output fuses	2 x 6.3 A FF / 250 V (super-fast)
Speaker outputs	Ensemble SYNERGIA binding posts, accepting 6 mm bananas (100 ampere-rated) 4 mm bananas 8 mm spades 10mm² – AWG7 nude cable
Dimensions (wdh)	395 x 315 x 135 mm (15.5″ x 12.4″ x 5.3″) 550 x 430 x 350 mm (21.6″ x 17″ x 13.8″) boxed
Weight	15.5 kg (34 lbs) net, 19 kg (42 lbs) shipping weight
Accessories	TUBESOX™ tube dampers FLEXO™ shielded power cord (1.5 m) optional ZORBO™ equipment platform
Warranty	2 years on parts (tubes 6 months) with the exception of all cases of failure due to mishandling, unauthorized modification, or overvoltage.

ensemble_Isolink_front — The ISOLINK is much more than a power line filter, because it is not a filter in the ordinary sense. It operates without need for AC grounding (as filters normally do), and thereby avoids a potential source of pollution and degradation, and it does what power line filters cannot do: the galvanic isolation between primary and secondary, between what is usually the power drawn from a wall socket and the power at its output.

ensemble® Massimo isolink duo™

Erotusmuuntaja

Galvanic isolation of sources (digital / analogue) by two independent isolation transformers.
1×175 VA max and 1x 250 VA max.*

Power factor correction.
*Check the maximum power required by your device.

Dimensions W x H x D: 395 x135 x 315 mm. Weight 18 kg.

2 Luminoso™ power cords 1.5 m included.

Al-Zorbo™ equipment platform recommended (optional).

Erotusmuuntaja

MASSIMO ISOLINK DUO ™ 5.300 €

Hinta sisältää alv 25.5 %

Katso tekniset tiedot/specifications

Type of transformer	split-core, for IEC class II (= earth-free) operation (4000 V isolation between primary and secondary)
Input	voltage switchable between 115 V 50/60 Hz and 230 V 50/60 Hz
Outputs	115 V / US (Nema 5-15) and 230 V / General European Type (SCHUKO) [Standard model]
Power rating¹⁾	DUO model : 250 VA and 175 VA constant (UNO model : 250 VA constant)
Fuses	250 VA transformer: 2 x 3.15 A T ; for 115 V operation 2 x 2 A T for 230 V 175 VA transformer: 2 x 2.5 A T ; for 115 V operation 2 x 1.6 A T for 230 V All fuses are 5 x 20 mm slow-blow, high-current (>35 A), 250 V type
AC ground	independent of transformer, with safety choke coil
’Power on’ light	linked to 250 VA transformer 115 V LED light (BA9s bayonet socket)
Chassis	epoxy-lacquered steel mechanical decoupling of transformers
Dimensions (wdh)	395 x 315 x 135 mm (15.5″ x 12.4″ x 5.3″) 550 x 430 x 350 mm (21.6″ x 17″ x 13.8″) boxed
Weight	DUO model: 18 kg (39.5 lbs), boxed: 21 kg (46 lbs) shipping weight (UNO model: 14 kg (30.8 lbs), boxed: 17 kg (37.5 lbs) shipping weight)

	¹⁾The actual power consumed by the equipment connected to the Isolink
Warranty	2 years on parts with the exception of faults due to mishandling, unauthorized modification or overvoltage

Swiss made quality

Kiinnostuitko?
Sopisiko emsemble® omaan nykysettiisi?

Ota yhteyttä – suunnitellaan.

Kysy mahdollista vaihtotarjousta!

Ota yhteyttä

What makes Ensemble different ?

Of course there are many very good reasons as shown further along.
First of all, beside having exceptional qualities, a true High End product for us is one that has a level of maturity that obviates the need for regular updates or Mark II, etc. versions.

This means long product life cycles, long-term pride of ownership.

Small wonder then that 15 or 20 year old Ensemble equipment is still in treasured use.

Ensemble equipment is a true asset.
